HD 4K 8MP White Bullet CCTV Security Coax Camera AHD+TVI+CVI+CVBS / 2000 + TVL Analog Infrared Indoor/Outdoor Color D/N

Product ID CPV-HDIRBFIO-4K
List Price: $195.00
Price: $58.00

4 in 1 Mode via OSD - BNC Video output:
BNC Coax AHD/TVI/CVI 4K or Standard Analog 960H/2000+ TVL Bullet IR Fixed Lens Camera

The CPV-HDIRBFIO-4K is a 4-in-1 bullet HD 4K infrared surveillance camera with a 90 degree viewing angle that supports the following video formats: AHD, TVI, CVI, and standard analog (CVBS). The AHD, TVI, and CVI video modes support 8 megapixel / 4K resolution (3840 x 2160). The standard analog mode (CVBS) supports 960H resolution (960 x 480). The appropriate video mode can easily be selected by using the small joystick that is attached to the camera's OSD video cable.  The CPV-HDIRBFIO-4K has 12 built-in infrared LED's that enables the camera to see in complete darkness up to 60 feet.

Night Vision from up to 60ft away

Image Resolution Comparison

Key Features:

  • OV12895 + NVP2481 1 Image Sensor
  • 4K HD Video Resolution (3840x 2160)
  • Supports AHD, TVI, CVI, and Standard Analog CCTV (CVBS) mode
  • 960H Resolution in CVBS Mode
  • 20M IR Distance
  • IP66 Weatherproof Housing - Indoor / Outdoor
  • OSD Controls via Cable
  • DC12V 550mA

Model NO.

CPV-HDIRBFIO-4K

Video Output Mode

AHD/TVI/CVI/CVBS

Camera

Image Sensor

OV12895 + NVP2481

Image Resolution

4K (8.0 MP)

Effective Pixels

3840 (H) ×2160 (V)

TV System

PAL/NTSC

Video Output Mode

AHD/TVI/CVI/CVBS

Electronic Shutter

AUTO/ 1/50-1/100,000sec

S/N Ratio

≥50dB

Scanning System

Progressive Scan

Lens

Focus Length

4mm lens; F1.0

Focus Control

Fixed

Lens Type

Fixed

Pixels

8M Pixels

Auto Iris Support

N/A

Night Vision

Infrared LED

14μX12PCS

Infrared Distance

20M

IR Status

Under 10 Lux by CDS

IR Power On

CDS Auto Control

Camera Features

Starlight

/

Day/Night

YES

OSD Menu Language

YES

White Balance

AUTO / MANUAL

Gain Control

AUTO

Noise Reduction

3D NR

Picture TVjustment

YES

WDR

N/A

OSD Support

YES

Dip Switch

N/A

General

Waterproof

IP66

Dual Voltage

N/A

IR Cut Filter

YES

Heater

N/A

Audio

N/A

Operation Temperature

-10 ~ +50 RH95% Max

Storage Temperature

-20 ~ +60 RH95% Max

Power Source

DC12V±10%,550mA

Dimension

 200(W) x 65(H) x 71(D)mm

Weight

600g

(Power supply not included see Accessories)
 *  Regular Stocking Item

Download High Resolution PDF
*Specification & Illustrations are subject to change without prior notice
