Display
|
Supports up to 480/400 fps
|
Compact and Advanced mode
|
Auto Scan with full screen display under 1, 4, 8, 9, 13, 16, 32-camera display modes
|
Digital zoom in for specific area
|
Pan/Tilt/Zoom (PTZ) cameras: PTZ script is available for adding new protocols
|
Auto Gain control (AGC) balance image quality
|
Night view ability
|
Noise reduction filter
|
Recording
|
Video compression: Advanced MPEG4 and H.264 compression
|
Supports 352x240, 640x240, 720x480/ 720X576 (NTSC/PAL)
|
Recording rate (NTSC/PAL): 160/128 at D1 resolution
|
Two types of de-interlace method: optimized for static scene or dynamic scene
|
Recording modes: Alarm trigger/ Motion Detection/ Smart/ Audio Detection/ Continuous/ Schedule recording
|
Programmable masking zone blank under recording modes
|
Intelligent shield protects privacy
|
Auto recycling when storage disk is nearing full
|
Live HDD size estimation tool
|
Supports network storage devices
|
Search & Playback & Backup
|
Real-time playback: instant playback
|
Powerful search: by date, time, camera, area, event, vision, and log file
|
Bookmark function for quick link
|
Complete playback control: playback, backward playback, fast forward/ backward playback, forward/ backward frame-by-frame playback
|
Digital zoom-in for specific area
|
Export single frame to BMP file and print out
|
Output “AVI” file for video clip
|
Built-in DVD-RW backup to CD/DVD
|
Backup device: flash memory , RAID, NAS, External HDD (up to 6HDDs) and 1 internal SATA HDD
|
Remote Access
|
Simultaneous multiple remote live/record video via standard web browsers
|
Backup remotely
|
Central Management System to connect up to 1000 DVRs
|
Remote monitoring/remote recording/playback remote recording/playback server recording
|
Full control of PTZ cameras remotely
|
WebViewer/ PDAViewer/ iPhoneViewer/ HandyViewer/ SmartViewer (for Symbian/Windows Smart phone)
|
2-way audio communication
|
1, 4, 9 and 16 screen divisions
|
Remote E-map
|
Choose from dial-up, Internet or LAN speed
|
Dispatch server allows you to broadcast video stream to the public
|
Schedule
|
Record, Network enable, backup, reboot, alarm, and relay control
|
Scheduled setting break down to 15-minute
|
One time or weekly repeat schedule
|
E-map
|
Showing the positions and status of camera, sensor, and relay
|
Extend to 8 maps
|
Alarm Notifications
|
E-map notifications
|
FTP notifications
|
Voice modem call out notification
|
Turn relay on (light switch, alarm, etc.)
|
Plays warning sound (can be re-recorded)
|
Start recording on multiple cameras (capture video from different angle)
|
Send TV-out signals
|
Launch E-maps
|
Enlarge camera view
|
Send SMS/MMS (requires SMS modem)
|
Send event to Central Management System
|
Alert messages helps security follow proper standard operational procedures
|
Web Tools
|
Remote backup: gradually backup recorded data from internet
|
Alarm Messenger: receive alarm notice on any PC
|
User Access
|
Setup as many users as you like with their own individual passwords
|
Each user can be pre-configured to perform only certain actions (e.g. access specific cameras remotely)
|
I/O Card
|
Built-in up to 4 sensors in/relays out
|
Supports up to 128 sensors in/ relays out via E-I/O box
|
