Model
|
CPV-XMPIRVFD-5SN
|
|
|
Sensor
|
1/2.8" Sony Starvis/Starlight 335 CMOS sensor
|
|
|
|
|
Processor
|
Embedded RTOS, dual-core 32-bit DSP
|
|
|
|
|
Lens
|
2.8-12mm Motorized Zoom Lens
|
|
|
Day & Night
|
Dual Optical Filters, Day/Night modes auto switch
|
|
|
IR LED
|
30 IR LEDs IR Range 30m (98ft.)
|
|
|
Minimum Illumination
|
color 0.001Lux@F1.2 black/white 0.0001Lux@F1.2
|
|
|
|
|
Shutter Speed
|
1/50(1/60)s to 1/10,000s
|
|
|
Privacy Masking
|
Up to 4 area
|
|
|
Video
|
|
|
Video Compression
|
H.265, H.264 ], support dual stream, AVI;
0.1M~8Mpbs variable
|
|
|
|
|
|
|
Resolutions
|
5MP@20fps/4MP@30fps
|
|
|
Frame Rate
|
1~30f/s variable
|
|
|
Dual stream
|
Main Stream 2Mbps~6Mbps, Sub Stream 512kbps~2.5Mbps (adjustable)
|
|
|
Image Settings
|
AE Reference, BLC, White Balance, DWDR, AGC
|
|
|
Snapshot
|
JPEG format
|
|
|
Noise Reduction
|
2D/3D-NR
|
|
|
AGC & WB & Exposure
|
Auto Gain Control, Auto White Balance, Auto Exposure
|
|
|
Audio
|
|
|
Audio Input/Output
|
1/1
|
|
|
Network
|
|
|
Network Protocol
|
RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP etc
|
|
|
Safety
|
Password protection
|
|
|
Water Mark
|
Support
|
|
|
SD card
|
Supports upto 128G C10 MicroSD / TF Card
|
|
|
Compatibility
|
Onvif 2.4
|
|
|
Max. User Acess
|
10 users
|
|
|
APP
|
Xmeye for Iphone & Android devices
|
|
|
System Integration
|
|
|
Analytics
|
Motion detection
Video loss detection
Video blind detection
Area cross detection
Human Detection
|
|
|
Alarm I/O
|
1/1
|
|
|
Alarm Event
|
Motion Detect, Video Loss, Video Cover, Network Abnormal
|
|
|
Alarm Responses
|
Snapshot, Email Alert, Start to Record , FTP Upload
|
|
|
|
|
Environmental
|
|
|
Temperature
|
-20℃ (-68°F) ~ 60℃ (140°F)
|
|
|
Humidity
|
< 95% (No condensing)
|
|
|
Vandal Resistance
|
IK10
|
|
|
General
|
|
|
Casing
|
Superior aluminum alloy, Good cooling effect
|
|
|
Dimension
|
|
|
|
Weight
|
Around 1lbs
|
|
|
Power (POE)
|
DC12V Buit-in POE
|
|
|
Connectors
|
RJ45; DC; RCA
|
|
|
Languages
|
English, Spanish, German, French, Italian, Russian, Japanese, Korean, Portuguess, Greek, Turkish, Polish, Roman, Arabic, Indonesian, Swedish, Czech, Bulgarian, Slovakia, Chinese
|
|
