Model
|
CPV-SNDL-4K
|
|
Camera
|
|
Image Sensor
|
1/2.7" GALAXYCORE GC5623 CMOS x2
|
|
Soc Chip
|
Sigmastar SSC359G
|
|
Effective Pixels
|
4096(H)×1944 (V)
|
|
Exposure Shutter
|
AUTO/Manual: 1/10s ~ 1/8000s, Max Shutter speed adjustable
|
|
Day/Night
|
Auto (Active/passive/schedule)/Day/Night, switch threshold, sensitivity, anti-flicker (Auto/50Hz/60Hz)
|
|
Image Adjust
|
Brightness, Saturation, Sharpness, Contrast, Denoise (0-100%) adjustable
|
|
White Balance
|
AWB/MWB
|
|
WDR
|
No
|
|
Light Mode
|
Smart(dual-light) / IR / White light, adjustable
|
|
Light Control
|
Auto/Manual, Brightness level (0-100%) adjustable
|
|
DNR
|
2D/3D DNR
|
|
Encode
|
|
Video Standard
|
H.264/H.265/MJPEG
|
|
Video Resolution
|
Main Stream: 20fps@8MP (4096x1944) (default)/1920x1080P
Sub stream: 20fps@1024x480(default)/768x360
(*Note: MJPEG max 1080P)
|
|
Video Bitrates
|
Mainstream: 64kbps-12Mbps
Sub stream: 64kbps-2Mbps
VBR/CBR, quality (1-9), GOP (1-128)
|
|
Image Snapshot
|
Mainstream (HD)/Sub Stream (SD) snapshot
|
|
Image Rotation
|
No
|
|
Border Crop
|
No
|
|
Image Mirror
|
horizon / vertical / horizon & vertical adjustable
|
|
OSD Overlay
|
Font size (1-4), position, Time, Title, AM/PM, Color, User OSD, Alarm OSD
|
|
Privacy Mask
|
4 areas
|
|
Region of Interest
|
ROI: Each stream support 8 areas
|
|
Audio Standard
|
G.711-u/G.711-a/AAC/PCM, AEC
|
|
Built-in Mic
|
Yes
|
|
Built-in Speaker
|
Yes
|
|
Stitch Distance adjust
|
1 - 50000mm adjustable
|
|
Led
|
|
IR Led
|
3pcs IR Array Leds
|
|
White Led
|
2pcs Warm Light
|
|
Light Distance
|
20-30 M
|
|
Lens
|
|
Focal length
|
2* F1.6 2.8MM Fixed Lens
|
|
Language
|
|
English, Japanese, Korean, German, Polish, Italian, Turkish, Ukraine, Russian, etc.
|
|
Smart Detection
|
|
Motion Detection
|
Yes
|
|
Digital IO Alarm
|
1 pair Alarm-in/Alarm-out, normally open/normally close (optional)
|
|
Human Vehicle Detection
|
Yes, (2-20 meters)
|
|
Cross Line Detection
|
Yes, 4 lines
|
|
Perimeter protection
|
Yes, 4 areas
|
|
Face Detection
|
Yes, (1-5 meters)
|
|
Target Detection Type
|
Human Shape, vehicle, non-motor vehicle, Pet, Face(12px-1000px)
|
|
Trigger Action Linkage
|
Snapshot, Record, Relay (Red-blue LED flash) optional, White LED Flash, Voice siren, Micro-SD, Email, FTP, NAS storage (NFS)
|
|
Simultaneous Detection
|
Maximum 16 targets simultaneous detection
|
|
Storage Type
|
Schedule/Trigger: Micro-SD (512G), Email, FTP, NAS (NFS)
|
|
Reset Button
|
Yes (with reset voice)
|
|
Network Services
|
|
Protocol
|
HTTP(s)/RTSP/FTP/SMTP/DHCP/NTP/DST/RTP/RTMP/P2P/
HiK/IPv4/IPv6/NFS/DDNS
|
|
IP Address Filtering
|
Yes (Allow list, Deny list)
|
|
P2P Mobile APP
|
Android, IOS
|
|
Web Access
|
IE, Firefox, Chrome, Edge, Safari, etc.
(Windows/Linux/Mac/Chromebook/Tablet/Mobile phone)
|
|
PC Tool
|
Windows, Mac
|
|
ONVIF
|
23.12 compatible (profile S G T M)
|
|
General
|
|
Network Port
|
1-RJ45, 100Mbps, POE(IEEE802.3af)
|
|
Power Supply
|
12 VDC ± 10%
|
|
Power Consumption
|
< 10 W
|
|
Operating Temp.
|
-20℃-(+60) ℃, 10%-90%RH
|
