The CPV-PVF600DNSNH is a Sony Body-Worn surveillance camera that is capable of capturing video at an amazing 600 lines of resolution / 960H CCTV resolution. The iPVF600DNSNH also comes with the built in ultra-low-light Sony Starlight sensor that provides sharper and clearer images at night.
Model NO
CPV-PVF600DNSNH
VIDEO
Image Device
1/3" Sony SUPER-HAD CCD
TV System
NTSC
Total Pixels
PAL:795(H)*596(V);NTSC:811(H)*508(V)
Effective Pixels
PAL:752(H)*582(V);NTSC:768(H)*494(V)
Scanning System
2:1 Interlace
Synchronization
Internal
Horizontal Resolution
600TVL
Min. Illumination
0.02lux / F1.2
S/N Ratio
>48dB(AGC OFF)
Video Output
1Vp-p,75ohm, BNC
LENS
Lens Type
C/CS Mount
OPERATIONAL
Day & Night
star-light
Backlight Compensation
ON/OFF Selectable
AES
Iris
Auto
Exposure Mode
EE/AI Selectable
Gain Control
AWB
White Balance
Auto; Range:3200~10000K
Electronic Shutter Speed
1/50~1/100,000sec(PAL),1/60~ 1/100,000sec(NTSC)
ENVIRONMENTAL
Operation Temperature
-10℃ - +50℃
Storage Temperature
-20℃ - +60℃
Application
Indoor
Outdoor
Matched the outdoor Housing for waterproof Protection
ELECTRICAL
Adapter Requirement
DC12V/AC24V Power
MECHANICAL
Color
Black
Dimensions
118*52*49mm
Net Weight
190g
(Power supply and Lens not included see Accessories) Download High Resolution PDF
