CPV-SW24G-1 with 24 10/100/1000Mbps PoE port, all ports support wire-speed forwarding, 2 gigabit optical interfaces (SFP port) for high-speed connection. It supplies power for device support IEEE802.3af/at standard, so the user needn’t to worry about the PoE switch would damage the non PoE device. Also, when the PoE device is disconnected, the PoE switch will stop providing power. The product is highly integrated design, lightweight, simple operation, suitable for medium or large office. Based on gigabit network technology, avoid network traffic and have a good network adaptability. Used (802.3az) Green Ethernet technology, by detecting of the length cable and the work load, automatically adjust the signal strength without reducing the operation performance and efficiency of the device, reduce energy consumption and protect the environment.
Features
Gigabit Ethernet Uplink Ports
Hardware Specification
Port
24 10/100M/1000Mbps PoE RJ45 ports （Port1～24）
Network Standard
2 SFP Gigabit port（Port25~26）
IEEE802.3i 10BASE-T
IEEE802.3u 100BASE-TX
IEEE802.3x Flow Control
IEEE802.3af/at Power over Ethernet
IEEE 802.3，IEEE802.3ab，IEEE802.3az
Network Media
10Base-T：UTP category 3 cable
100Base-TX：UTP category 5 cable
1000Base-T：UTP category up 5 cable
Speed
100/1000Mbps Full Duplex，
Function Standard
Network Interface：100BASE-T or 1000BASE-TX Ethernet RJ-45 Port
Bandwidth：48Gbps
Network delay（100 to 1000M bps）：Max 20 microseconds（64 Byte）
MAC Address 8K
Forwarding rate ：
10Mbps：14880pps
100Mbps：148800pps
1000Mbps：1488000pps
LED Light
System：Power, PoE
Each Port Link/ACT/Speed,10M/100M/1000
Mbps Network
Power Supply
PoE Total power：360W（All PoE Port，Port 1～Port24），single port Max 30W
Power Pin
400W internal power adapter
1 2 + 3 6-
Physical Size
Size：440mm x 290mm x 44mm
Weight ：5.5 kg
Temperature
Operating Temp：0°~40°C（32°~104°F）
Storage Temp：-40℃~70℃（-104°~158°F
Operating Humidity：10%~90% Non-condensing
Storage Humidity ：5%~90% Non-condensing
Certification
CE FCC RoHS
Warranty
1 year
Download High Resolution PDF *Specification & Illustrations are subject to change without prior notice *All other trademarks or registered trademarks are the property of their respective owners.
