Model
|
CPV-PTZIRTAW18X-5MP
|
|
Video
|
Sensor
|
5.0 megapixel 1/2.8" SONY335 low lux CMOS
|
|
Video resolution
|
Main stream: 2560x1920@15fps, 2560x1440@15fps
|
|
Sub stream: 800x600/800x448@25fps, 640x480/640x352@25fps
|
|
Minimum illumination
|
Day mode: 0.1LUX; Night mode: 0.01LUX
|
|
Video compression
|
H.264/H.265
|
|
Lens
|
5mm~90mm 18X optical zoom auto focus lens
|
|
View angle
|
61.4°~3.6°
|
|
Night vision
|
IR Distance 100-150M
|
|
Audio
|
Audio compression
|
G.726/G.711
|
|
Audio code rate
|
8Kbps, 16bit
|
|
Audio
|
2-way Audio;
|
|
Alarm
|
Motion detecting alarm
|
Can set 4 independent detection region (1-100 sensitivity can be set)
|
|
Alarm linkage
|
Alarm send pictures to the mailbox,
|
|
Alarm upload pictures and videos to the FTP server,
|
|
Alarm record pictures and videos to Micro SD card,
|
|
Alarm mobile phone message push,
|
|
Alarm trigger sound alarm
|
|
Alarm recording
|
Support Micro SD card and PC client linkage alarm recording
|
|
Wi-Fi
|
App Name
|
Camhipro
|
|
Wireless
|
IEEE 802.11 b/g/n
|
|
Wi-Fi Range
|
20-25 Meters
|
|
Network
|
Ethernet
|
10Mbps/100Mbp RJ45 Ethernet
|
|
Onvif protocol
|
Support ONVIF 2.4 (backward compatible),
TCP/IP,HTTP,TCP,UDP,SMTP,DHCP,DNS,P2P
|
|
Storage
|
Micro SD card
|
Support up to 128G micro SD card
|
|
Recording mode
|
Alarm record, timing record
|
|
Video playback
|
Support APP, IE browser, remote client play and download the video
|
|
PTZ
|
Rotation angle
|
Horizon: 0°～355°, Vertical: 0°～90°
|
|
Horizontal / Vertical speed
|
Horizontal speed: 20°～ 40°/S; Vertical speed: 10°～ 20°/S
|
|
Preset
|
Support 8 preset points
|
|
General
specification
|
Power
|
DC12V 3A
|
|
Power consumption
|
Day Mode: 5W; Night Mode: 12W (IR Light Turn on)
|
|
Operating environment
|
Environment -10℃~+50℃(-4℉~+140℉),
|
|
Humidity<80%
|
|
Waterproof level
|
IP66
|
|
Product Details
|
Size: 7 inch×5 Inch×9 inch(L×W×H); Weight: 3 pounds
|
|
Reset button
|
Support
|
