System
|
CPU：TI TMS320DM368
Flash：256MB
RAM：128MB
|
|
Image Sensor
|
High Quality 1/2.5”CMOS
|
|
Sensitivity
|
0 Lux(IR ON)
|
|
IR LED
|
40PCS
|
|
Lens
|
Varifocal 3.5-10mm F1.6
Removable IR-cut filter for day & night function
|
|
Video
|
H.264: 30 fps at 1920x1080, Highest Resolution: 10 fps at 2592x1920
|
MPEG4: 30 fps at 1920x1080
|
MJPEG: 30 fps at 1920x1080, Highest Resolution: 10 fps at 2592x1920
|
Compression: H.264, MPEG-4 & MJPEG Streaming: Triple Codec (H.264、MPEG-4、JPEG) Selectable
|
Support Simultaneous multiple streams
|
BNC connector for video output; NTSC/PAL video output switch
|
|
Image Settings
|
Adjustable image size, quality, and bit rate
|
Time/Date stamp and text caption overlay.
|
Configurable brightness, contrast, saturation, sharpness, white balance and exposure
|
AGC、AWB、AES、BLC
|
|
Audio
|
Format
|
MPEG-4 AAC audio encoding
|
G.711 audio encoding
|
Support Audio line-in for external microphone
|
|
Networking
|
Interface
|
10/100 Mbps Ethernet, RJ-45
|
|
Supported Protocol
|
IPv4,TCP/IP,DHCP,HTTP,RTSP,SNTP,DNS
|
|
Supported Browser
|
Microsoft Internet Explorer 6.0 or above
QuickTime Player is necessary add-in for Safari, Chrome or Firefox
|
|
Alarm and Event Management
|
Motion Detection
|
|
Face Detection
|
|
Alarm I/O (2 x DI/1 x DO)
|
|
Event notification using SMTP or FTP
|
|
Users
|
8 clients on-line monitoring at the same time
|
|
Multi-level user access control with password protection
|
|
Maintenance
|
Supports online firmware upgrade
|
|
I/O
|
RJ-45 Ethernet x 1,DC Jack x 1,BNC Video out, Phone Jack Line in x 1,Alarm I/O, Reset Bottom
|
|
IP Rating
|
IP66
|
|
Power
|
DC12V or PoE IEEE802.3af Class 0
|
|
Max. Power Consumption
|
3.6W(IR OFF),7W(IR ON)
|
|
Weight
|
Net weight：965g
|
|
Dimension
|
315 × 88 × 87 mm
|
|
Operating Environments
|
Temperature: 0 ~ 45 °C
Humidity: 90%
|
