The CPV-HDPTZ18xFIO-1080SN is an infrared PTZ camera with 4 selectable video formats: AHD, TVI, CVI, and traditional analog CCTV (CVBS). This pan tilt zoom camera supports 1080p resolution (AHD, TVI, and CVI) and 960H resolution in traditional analog CCTV mode (CVBS). The appropriate video mode can easily be selected using the small joystick that is attached to the camera's OSD video cable. The CPV-HDPTZ18xFIO-1080SN comes with built in infrared night vision so that it can see in complete darkness. It also has an 18x optical zoom range via the 4.7 ~ 84.6mm lens and a max IR distance of 196 feet (60 meters).
Model NO.
CPV-HDPTZ18xFIO-1080SN
Camera
Image Sensor
Sony IMX323
Horizontal Resolution
2MP
S/N Ratio
>50db
PTZ
Horizontal Rotation
45°/S
Speed
0°~360°
Range
Tilt Rotation Speed
30°/s
Tilt Rotation Range
0°~90°
Auto Flip
Support
Ratio Speed
360° Scan
A-B Scan
Preset Points
220
Guard Tours
3 groups
Guard Points
Max.16 points
Lens
Focus Length
4.7mm-84.6mm
Focus Control
18X Optical Zoom
Night Vision
Infrared LED
￠42x6PCS
IR Range
60m
Auto Control IR LED
PWM
Communication
UTC
Protocol
COAXAIL CABLE
Interface
Audio
/
Alarm
General
Weatherproof
IP66
Operating
Indoor: 0°~ +40° Outdoor: -40°~ +
Temperature
60°
Operating Humidity
≤90% Non Condensing
Heater & Blower
Auto temperature control
Power
DC12V 2A/3A
Lightning Protection
Transient voltage 6000V
Dimension
295x280x170(mm)
Weight
4.2 KG
* Regular Stocking Item Download High Resolution PDF *Specification & Illustrations are subject to change without prior notice
