Model NO.

CPV-HDIRDFIO24C-5SNA

Video Output Mode

AHD/CVI/TVI/CVBS

Camera

Image Sensor

IMX335 + FH8558M

Image Resolution

5.0 MP

Effective Pixels

2592×1944

TV System

PAL/NTSC

Video Output Mode

AHD/CVI/TVI: 5Mp@30fps

Electronic Shutter

1/25s~1/50,000s , 1/30s~1/60,000s

S/N Ratio

≥50dB

Scanning System

Progressive Scan

Lens

Focus Length

Board Lens 2.8mm

Focus Control

Fixed

Lens Type

Fixed

Pixels

5M Pixels

Auto Iris Support

N/A

Night Vision

Infrared LED

14μX2 PCS

Infrared Distance

25M ~65 feet

IR Status

Warm White Lens(4000K)

IR Power On

CDS Auto Control

Camera Features

Starlight

N/A

Day/Night

YES

OSD Menu Language

YES

White Balance

AUTO / MANUAL

Gain Control

AUTO

Noise Reduction

DNR

Picture TVjustment

YES

WDR

DWDR

OSD Support

YES

Dip Switch

N/A

General

Waterproof

N/A

Dual Voltage

N/A

IR Cut Filter

YES

Heater

N/A

Audio

N/A

Operation Temperature

-10℃ ~ +50℃ RH95% Max

Storage Temperature

-20℃ ~ +60℃ RH95% Max

Power Source

DC12V±10%,550mA

Dimension

￠108 x 90(H) mm

Weight

550g ~1.2 pounds
