Serial & Virtual Serial Over IP Software to another PC or DVR

Product ID CPV-PCCOM-IP
List Price: $109.00
Price: $55.00

CPV-PCCOM-IP software lets you access devices located on the remote PC as if they were plugged into your own computer. Applications using such remote devices should be treated as local ones.

For example, to share a serial device over Ethernet you need to install iPCCOM-IP on both sides of the connections (client/server), thus establishing a "serial tunnel". On the server side, iPCCOM-IP converts serial data into TCP/IP data and hooks it over the Ethernet to the client side, where iPCCOM-IP converts TCP/IP packages back into the serial data. This procedure can also be used to send Windows based POS text or transaction information to any DVR that supports POS integration via serial.

Send text or transaction information from Windows based POS to our DVR:

You can share your serial printer, or the text going to another physical serial port, or create a virtual port by installing the software on the Windows based POS system and create the tunnel between the POS and our PC Based DVR via UDP Port.  Since our PC Based DVRs have direct support for IP based POS you do not have to purchase or install iPCCOM-IP on the DVR. This process eliminates the purchase of addtional cables, connectors, adaptors and in some cases text inserters.  This process also allows you to connect up to 16 or 32 POS to a single DVR without having to purchase an additional serial card, edge port, etc.

Send Text or transaction information from Windows POS to other DVRs that support serial connection

Key Features:

  • User-friendly and a convenient program interface
  • Share your serial ports and devices with others over the TCP/IP network
  • Both the TCP/IP and the UDP/IP protocols are supported
  • Easily connect to a remote computer using TCP/IP Telnet protocol, with the RFC 2217 Telnet extensions for COM Port Control
  • Share an unlimited number of serial ports simultaneously for remote connections
  • No limitation on the quantity of virtual serial ports or connections created (except your system resources)
  • Manage port signal lines states in connections
  • Verify connection's integrity by using "send command to keep connection alive" feature
  • Ability to send data on certain event in UDP connection type (when block of data reaches certain size, on receiving special char and on certain timeouts)
  • Serial port names are not restricted to COMxx only and may have virtually any name
  • High speed data exchange from/to virtual serial port (up to 256 Kbits)
  • Virtual serial ports work like real physical ports
  • Automatically restore connection within a customizable timeout on connection breaks
  • Small packet transmission speed can be increased by disabling Nagle algorithm
  • Dynamically change the COM port parameters without necessity to reopen or re-create it
  • Ports could be automatically configured every time you boot your PC
  • Map your real serial port to any other virtual or real port
  • Customize advanced connection settings when you switch to Advanced mode
  • Easily track all program's activity in "Activity log"
  • Secure your data transmission over network by authorization system and traffic encryption
  • Connection speed in serial port pairs is much more reliable and faster than in physical link
  • TCP client can connect to various servers with different encryption and/or authorization parameters
  • Fully compatible with Hyper Threaded and multi-processor systems
  • Works in virtual machine
  • Install this application on two computers to provide client-server architecture
  • Connect to several remote computers simultaneously
  • Renaming full port names in Device Manager
  • Separated traffic statistics for:

             - a serial port
             - each of the TCP connections
             - UDP packets

  • Strict baud rate emulation option for virtual ports (required for DVRs
  • Possibility to abort specified TCP connection

Windows Compatible with:

  • Windows 7 32-bit & 64-bit
  • Windows Vista 32-bit & 64-bit
  • Windows XP 32-bit & 64-bit
  • Windows 2008 32-bit & 64-bit
  • Windows 2003 32-bit & 64-bit
  • Windows 2000
  • Windows NT 4.x

This is a non-refundable item and we suggest that you download our 14 day trial version before making the purchase. This software is iLink Professionals branded and the license key will be emailed to you with-in 24 hours of the purchase. No key is required for the 14 day trial and you don't have to download and reinstall it after the purchase if you are using the trial version.


14 Days Trial Software



Price: $55.00
