Model |
CPV-SMAFD-4kSAI |
|
Camera |
|
Image Sensor |
1/2.7" 8MP CMOS |
|
Effective Pixels |
3840 × 2160 |
|
Electronic Shutter |
AUTO/Manual: 1/10s ~ 1/10000s, shutter threshold |
|
Min. Illumination |
0.01Lux@F1.2 (AGC ON), 0 Lux IR on |
|
Day / Night |
Auto / Color / (B/W) / Timing |
|
WDR |
Digital WDR |
|
White Balance |
Auto / Manual |
|
BLC / HLC |
Support |
|
DNR |
2D/3D DNR |
|
Light Control |
Auto/Manual, Mode switch, Brightness level, OFF, Light ON Illumination |
|
License Plate Mode |
Yes |
|
Other |
Multi-lines OSD, Custom Title, Privacy Mask, Flip, Reset button |
|
Encode |
|
Video Standard |
H.264 / H.265 / H.265+ |
|
Video Resolution |
Main Stream:
20fps@3840x2160, 25fps@3072x2048, 30fps@5MP / 2560×1440 / 2304×1296 / 1920×1080 / 1280×720
Sub Stream:
30fps@D1/VGA (640×480) / 640×360, 480×360, CIF (352×288) |
|
Video Bitrates |
512Kbps - 12Mbps, VBR / CBR |
|
Audio Standard |
G.711-u/G.711-a/AAC |
|
Built-in Mic |
Yes, Audio Echo Cancellation |
|
Built-in Speaker |
Yes, Two-way Audio |
|
Memory Slot |
Yes, maximum 512GB |
|
OSD Overlay |
Title and Time overlay, Snapshot |
|
Smart Detection |
|
Motion Detection |
Support |
|
Target Detection |
Human and Vehicle Detection |
|
Led |
|
Led |
1pc IR & blue flashing & 1pc Warm-light Led |
|
Light Distance |
IR Range 25-30 M, lighting range:20m |
|
Lens |
|
Focal length |
2.8 mm |
|
Language |
|
Languages |
English, Simplified Chinese, Chinese Traditional, Deutsch, Italian, Turkish, Polish, Korean, Japanese, Russian, Ukrainian, Persian. |
|
Network Services |
|
Protocol |
HTTP / RTSP / FTP / NFSv3 / SMTP / DHCP / NTP / RTMP, etc. |
|
P2P |
Yes |
|
Web |
IE, Firefox, Chrome, Edge, Safari, etc. |
|
Media |
CMS, Android, IOS |
|
ONVIF |
17.06 compatible |
|
General |
|
Network Port |
1-RJ45, 100Mbps. |
|
Power Supply |
12 VDC ± 10% |
|
POE |
802.3af / at 48V |
|
Power Consumption |
< 8 W |
|
Operating Temp. |
-30℃-(+60)℃, 10%-90%RHv |
